typVol2Vol

Description

Vol2Vol interpolates the wave fields and return wave properties at given time and position. It has the multiple Surf2Vol classes and interpolation class. The Vol2Vol class structure is described in Fig. 3. The reconstructed HOS wave fields (snapshot of wave field) retrieved from Surf2Vol are used to construct interpolation data.

HOS result file holds modes amplitudes time series for the whole HOS simulation time. If we construct HOS wave fields and interpolation data structure for the whole HOS simulation time, not only the computation time is long but also a huge memory is demanded. Grid2Grid aims for construction of demanding wave fields for relatively short period and domain, it is not necessary to construct the whole HOS wave fields and interpolation data structure. Therefore revolving algorithm is applied just to update HOS wave fields adjucent to simulation time and constuct small interpolation data structure for efficient computation time and memory.

``Vol2Vol`` class structure

Fig. 3 Vol2Vol class structure

When Vol2Vol initialised, the Surf2Vol class array is allocated and initialise multiple Surf2Vol and connect those Surf2Vol class array with the revolving algorithm. The revolving algorithm determines which Surf2Vol should be updated and the order of Surf2Vol array for the efficient generation of interpolation data.

The subroutine correct with input \(t\) first determine HOS Surf2Vol correction index and Surf2Vol order based on input \(t\) and previous HOS time index. By using correction index and order, only necessary HOS Surf2Vol is updated and re-ordered to constructed for interpolation data. After interpolation data is constructed, it is delivered to the interpolation class. The interpolation class communicates with the bspline-Fortran module and constructs the interpolation data structure.

The subroutine getEta, getU, getPd and getFlow return interpolated values for given space and time from the constructed interpolation data structure.

Class (Type)

Class: Vol2Vol

  • Data:

    • nInterp_: Interpolation order (2: Linear, 3: Quadratic, 4: Cubic, … )

    • nSaveT_: Number of Surf2Vol wave fields (nSaveT_ \(>\) nInterp_)

    • HOSs2v_(:): Array of Surf2Vol class

    • itp2D_: Interpolation class for 2D waves

    • itp3D_: Interpolation class for 3D waves

  • Functionality:

    • initialize: Initialise HOS Vol2Vol class with HOS type, result file path, …

    • correct: Update HOS wave fields with real-time

    • getEta: Get interpolated wave elevation

    • getU: Get interpolated wave velocity

    • getPd: Get interpolated dynamic pressure

    • getFlow: Get flow information

    • destroy: Class destroyer

How to use

  • Initialise Vol2Vol

Call hosV2V%initialize(hosType, filePath, zMin, zMax, nZmin, nZmax, zMinRatio, zMaxRatio, iflag)

!   hosV2V              : Vol2vol Class (Type)
!   hosType             : HOS Type (Ocean or NWT)
!   filePath            : HOS result file path (modes_HOS_SWENS.dat)
!   zMin, zMax      : HOS grid z-minimum and z-maximul (vertical domain)
!   nZmin, nZmax    : Number of z-directional Grid
!
!   zMinRatio, zMaxRatio  (Optional)
!   : Ratio of maximum and minimum height of grid (default=3)
!
!   iflag : Wriging option (iflag = 1, write Grid2Grid information)

! or

Call hosV2V%initialize(dict)

!   hosV2V          :  Vol2vol Class (Type)
!   dict                : HOS dictionary to initialize HOS vol2vol (Type)

  • Correct Vol2Vol

Call hosV2V%correct(simulTime)

!   hosV2V              : Vol2vol Class (Type)
!   simulTime           : Simulation time (real time value)

  • Get wave elevation from Vol2Vol

eta = hosV2V%getEta(x, y, simulTime, iflag)

!   hosV2V              : Vol2vol Class (Type)
!   x, y                    : x and y position
!   simulTime       : Simulation time (real time value)
!
!   eta                     : Wave elevation
!
!   iflag (Optional)
!   : if iflag = 1, nondimensional x and y can be given (default = 0).

  • Get wave velocity from Vol2Vol

Call hosV2V%getU(x, y, z, simulTime, u, v, w, iflag)

!   hosV2V              : Vol2vol Class (Type)
!   x, y, z             : x, y and z position
!   simulTime       : Simulation time (real time value)
!
!   u, v, z             : Wave velocity ( x, y, z )
!
!   iflag (Optional)
!   : if iflag = 1, nondimensional x and y can be given (default = 0).

  • Get dynamic pressure from Vol2Vol

pd = hosV2V%getPd(x, y, z, simulTime, iflag)

!   hosV2V              : Vol2vol Class (Type)
!   x, y, z             : x, y and z position
!   simulTime       : Simulation time (real time value)
!
!   pd                      : Dynamic velocity (pd = p - rho * g * z)
!
!   iflag (Optional)
!   : if iflag = 1, nondimensional x and y can be given (default = 0).

  • Get flow information from Vol2Vol

Call hosV2V%getFlow(x, y, z, simulTime, eta, u, v, w, pd, iflag)

!   hosV2V              : Vol2vol Class (Type)
!   x, y, z             : x, y and z position
!   simulTime       : Simulation time (real time value)
!
!   eta                     : Wave elevation
!   u, v, z             : Wave velocity ( x, y, z )
!   pd                      : Dynamic velocity (pd = p - rho * g * z)
!
!   iflag (Optional)
!   : if iflag = 1, nondimensional x and y can be given (default = 0).

  • Destroy Vol2Vol

Call hosV2V%destroy()
