modGrid2Grid

Description

modGrid2Grid is not a class but a Fortan module which contains an array of Vol2Vol classes and subroutines to communicate with other languages. The module structure is depicted in Fig. 4. It has two static data which are input data array and Vol2Vol array not to have and update multiple Vol2Vol classes for efficiency and to save memory. When Grid2Grid is initialized from a program written in another language, it firstly check the input variables and return HOSIndex. If the same input variables are given, it returns the same HOSIndex and does not allocate nor initialise Vol2Vol. Other languages can distiguish different HOS wave theory by using the HOSIndex. The subroutines correct and get* can be called with HOSIndex, position and time.

The array size of modGrid2Grid is 100 by default (It can deal with 100 different HOS waves) but it does not consume much memory because classes of Grid2Grid are programmed with dynamic arrays and consequently only a few of static data are used. If more HOS wave theories are needed, the variable nMaxVol2Vol in src/modGrid2Grid.f90 can be changed to deal with over than 100 different HOS wave theory.

The functionality of modGrid2Grid is almost the same with Vol2Vol.

``Grid2Grid`` Module structure

Fig. 4 Grid2Grid Module structure

Subroutines

The interface between other languages with modGrid2Grid will be detailed in Interface.

Subroutines in modGrid2Grid follows ISO_C_BINDING.

Subroutines:

  • Initialise Grid2Grid

    • __modgrid2grid_MOD_initializegrid2grid

    • __modgrid2grid_MOD_initializegrid2griddict

  • Correct Grid2Grid

    • __modgrid2grid_MOD_correctgrid2grid

  • Get wave elevation

    • __modgrid2grid_MOD_gethoseta

  • Get wave velocity

    • __modgrid2grid_MOD_gethosu

  • Get dynamic pressure

    • __modgrid2grid_MOD_gethospd

  • Get flow information

    • __modgrid2grid_MOD_gethosflow

  • Get HOS simulation end time

    • __modgrid2grid_MOD_gethosendtime

  • Get HOS water depth

    • __modgrid2grid_MOD_gethoswaterdepth

  • Get logical data indicating HOS wave theory is initialized

    • __modgrid2grid_MOD_isgrid2gridinitialized
