PostGrid2Grid

Description

PostGrid2Grid is a HOS post-processing class. It generates 3D VTK files of wave fields for visualization and wave elevation time series computed from Vol2Vol class. Wave fields at desired simulation time and spatial domain and wave elevation time series can be re-generated at some provided wave probes position.

PostGrid2Grid algorithm is depicted in Fig. 5. PostGrid2Grid is initialised with input file. The input file postGrid2Grid.dict contains HOS grid information and post processing information which have dictionary format. PostGrid2Grid first reads and checks the input file and then build 3D visualization grid and wave probes. Vol2Vol class is also initialised. The subroutine doPostProcessing do time loop of correct. Subroutine correct first corrects the Vol2Vol class and gets the wave fields. If the grid option is set to no air mesh, 3D grid is fitted to wave elevation. It writes the results on files (3D VTK file and wave elevation time series).

Fig. 5 PostGrid2Grid Algorithm

Class(Type)

Class : PostGrid2Grid

• Data :

  • hosVol2Vol_ : Vol2Vol class

  • rectLGrid_ : Rectangular linear grid for 3D wave fields (VTK output)

  • waveProbe_(:) : Wave probe

• Functionality (Public) :

  • initialize : Initialise PostGrid2Grid class

  • correct : Correct Vol2Vol, rectLGrid_ and waveProbe_ and write output

  • writeVTK : Write 3D wave fields in VTK format

  • doPostProcessing : Do post processing

  • destroy : Destuctor of PostGrid2Grid class

• Functionality (Private) :

  • readPostG2GInputFileDict : Read PostGrid2Grid input file

  • checkPostG2GParameter : Check PostGrid2Grid input file

  • writeVTKtotalASCII : Write wave fields (Including air domain)

  • writeVTKnoAirASCII : Write wave fields (Grid is fitted to wave elevation)

  • writeWaveProbe : Write wave elevation time series

Input File of PostGrid2Grid

PostGrid2Grid needs the input file. The input file name is postGrid2Grid.dict. The input is recognized by dictionary(keyword + value with sub-dictionary). The special characters are treated as a comment (!, # and \\) and C++ style comment block is also allowed.

• PostGrid2Grid variables

### Select HOS dictionary and set post processing option ----------------------------------- #

Grid2Grid                   HOSDict;    # HOS dictionary

writeVTK                    true;   # 3D visualization option; true or false

writeWaveProbe      true;   # Wave probe option; true or false

• HOS dictionary

### HOS dictionary ----------------------------------- #

HOSDict
{
    type    Ocean;      # HOS solver type; NWT or Ocean

    filePath    example/modes_HOS_SWENSE.dat;   # HOS file path

    fileType    ASCII;  # Option; HOS result file type, ASCII or HDF5

    interpolationOrder  3;  # Option; 3:Cubic spline [Default]

    zMin        -0.6;       # HOS domain zMin
    zMax        0.6;        # HOS domain zMax

    nZMin       50;     # HOS domain nZMin
    nZMax       50;     # HOS domain nZMax

    zMeshType   meshRatio;      # Mesh type (uniform, sine, meshRatio)

    zMinRatio   3.0;    # Option, z<=0 meshing ratio (meshRatio)
    zMaxRatio   3.0;    # Option, z<=0 meshing ratio (meshRatio)

    writeLog        true;   # Option; write log option
}

• Simulation Dictionary

### Simulation dictionary ------------------------------------------- #

simulation
{
    startTime       2712.0;

    endTime         2812.0;

    dt              0.1;
}

• 3D visualization dictionary

### VTK mesh dictionary ------------------------------ #

vtkMesh
{
    airMesh     false;      # Air meshing option

    xMin         0.0;           # VTK mesh xMin
    xMax        100.0;      # VTK mesh xMax

    yMin         0.0;           # VTK mesh yMin
    yMax        100.0;      # VTK mesh yMax

    nX          50;             # VTK mesh nX
    nY          50;             # VTK mesh nX

    zMin        -0.6;           # VTK mesh zMin
    zMax        0.6;            # VTK mesh zMax

    nZMin       50;             # VTK mesh nZMin
    nZMax       50;             # VTK mesh nZMax

    zMeshType   meshRatio;      # Mesh type (uniform, sine, meshRatio)

    zMinRatio   3.0;    # Option, z<=0 meshing ratio (meshRatio)
    zMaxRatio   3.0;    # Option, z<=0 meshing ratio (meshRatio)

}

• Wave probe dictionary

### Wave probe dictionary ------------------------------------------ #

waveProbe
{
    waveProbeFile   waveElevation.dat;      # Output file name

    waveProbes
    {
        probe1
        {
            position  ( 0.0   10.0 );       # wave probe position
        }
        probe2
        {
            position  ( 0.0   15.0 );
        }
    }
}

How to use

!! Subroutine to run PostGrid2Grid -----------------------------------
Subroutine runPostGrid2Grid(inputFileName)
!! -------------------------------------------------------------------
Use modPostGrid2Grid                    !! Use PostGrid2Grid Module
!! -------------------------------------------------------------------
Implicit none
Character(Len = * ),intent(in) :: inputFileName     !! postGrid2Grid.inp
Type(typPostGrid2Grid)         :: postG2G               !! postGrid2Grid Class
!! -------------------------------------------------------------------

!! Initialize PostGrid2Grid with Input File
Call postG2G%initialize(inputFileName)

!! Do Post Processing
Call postG2G%doPostProcessing()

!! Destroy
Call postG2G%destroy

!! -------------------------------------------------------------------
End Subroutine
!! -------------------------------------------------------------------
